Specifications
| Lighting method | Transmission: 0/D (parallel light illumination, diffuse reflection reception) |
| Meet the standard | ASTM D1003/1044,IS0 14782,GB/T 2410,JJF 1303-2011,CIE 15.2,JIS K7105,JIS K7361,JIS K7136 |
| Integrating sphere size | Ф154mm |
| Light source | 400-700Nm Combined LED Light source |
| Sensor | PD Array Detector with CIE V (lambda) 2 Degree Visual Response |
| Transmittance range | 0-100% |
| Measurement aperture | Should 20mm/should 15mm/should 8mm/should 4mm (select single diameter) |
| Sample size | Thickness less than 170mm |
| Observer Angle | 2° |
| Observational Light source | D65,A,C |
| show | Pass/fail results |
| Measurement time | About 1.5s |
| Haze resolution | 0.1 unit |
| Haze Repeatability | 20 mm diameter, less than 0.15 (after the instrument is preheated and corrected, the standard haze sheet with a haze of about 30 is tested 30 times at an interval of 5 seconds) |
| stand-alone difference | 20 mm diameter, less than 0.5 (after the instrument is preheated and corrected, the standard deviation between the standard haze film and the reference value is tested at an interval of 5 s) |
| size | Length X width X height = 290X211X511mm |
| Weight | About 4.0kg |
| Power Supply | DC 24V, 3A power adapter Power Supply |
| Light source lifetime | More than 3 million measurements in 5 years |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port |
| Store data | 1000 master standards, 10000 samples |
| language | Simplified Chinese, Traditional Chinese, English |
| Temperature range | 0-40°C(32-104°F) |
| Temperature range | -20-50°C(-4-122°F) |
Packing list
Host X1, manual X1, certificate X1, warranty card X1, power adapter X1, quality management software (official website download) X1, data cable X1, 0% correction box X1, measurement diameter X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48581/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
