Specifications
| Measurement range | 250～6000kPa |
| Clamping Force | > 690Kpa (adjustable) |
| induction method | pressure converter |
| savings outcome | With printing function, it can print 10 sets of data to automatically calculate the average value |
| Display mode | High definition LCD display, digital A/D value progress rate 100 times/S, Test Accuracy |
| Force Unit | KGF/cm2, Lb/in2, Kpa (with Unit switching function) |
| resolution | 1kPa |
| Measurement error of indication | Better than +/- 1% FS |
| Variability of measurement indication | Better than +/- 1% |
| hydraulic speed | High Voltage 170 +/- 10ml/min |
| Film resistance | Raise 10mm, 170kPa~ 220kPa; Raise 18mm, 250kPa~ 350kPa |
| Clamp ring material | stainless steel |
| Upper chuck diameter | 93mm |
| Lower chuck diameter | 130mm |
| Hydraulic oil | silicone oil |
| Volume | 445*510*365mm |
| Weight | About 50KG |
| Power Supply | 1∮,AC220V |
| Standard configuration | 5 pieces of rubber film, 1 wrench, 10 correction pieces, and 1 bottle of silicone oil. |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
