Specifications
| Rated Voltage | AC220V |
| Rated Frequency | 50/60Hz |
| drive type | DC servo motor |
| Input Power | 1100 W |
| output power | 800 W |
| Rated torque | 355 N·cm |
| Duty Cycle | S1 (continuous) |
| Control mode | Knob control mode |
| Rotation speed adjustment range | 200~2000rpm |
| Rotation speed control type | stepless |
| Rotation speed digital display | LED |
| Overload protection function | Yes |
| Stirringrod fixing method | Quick turn chuck |
| Rotary collet clamping range | Ф3~16mm |
| Impeller configuration | Dissolved Impeller |
| Processing Capacity (H2O) | 120 L |
| processing viscosity | 100000 mPa.s |
| Environmental temperature | Not more than 40 ° C |
| Allowable Relative Humidity | Not more than 80% |
| Column lifting stroke | 500mm |
| Dimensions of the whole machine | 800x710x1235mm |
| Machine Weight | 35 kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48635/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
