Specifications
| Coating method | Bar + drawdown blade |
| Coating speed | 5~ 200Mm/s (< 5mm/s can be customized) |
| Coating size | 300 * 400Mm (can be customized) |
| Spreader speed | Digital display, different speeds |
| speed control | Infinitely variable speed |
| Coating table material | aluminum alloy |
| Vacuum Area | 300 * 400Mm (can be customized) |
| vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Bar effective application width | 300mm |
| Mayer Rod Thickness Range | 0~517.5 μm (Spreader thickness according to bar model) |
| Mayer Rod Accuracy | ±0.001mm |
| Drawdown blade type | Removable drawdown blade, easy to clean and replace |
| Drawdown blade Accuracy | ±0.003mm |
| Drawdown blade thickness range | 0~10Mm drawdown blade can be lifted |
| Vacuum pump size | 380*180*280mm |
| UV curing area | 300*400mm |
| UV light main peak wave | 36nm |
| UV Light Power | 400*2W |
| UV light curing wavelength | 350-450nm |
| switch | Aviation plug/separate switch |
| Light source spacing | 18*18mm |
| Light board height from Spreader | 20Mm (support customized adjustable height) |
| Host Power Supply | 220V 50Hz |
| Dimension | 630*410*520mm |
| Optional Accessories | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, silicone pad and Weight (for applications with uneven thickness of Spreader substrate), application width control baffle |
| customizable function | Jet system device, UV solid inclusion device, automatic inking system |
Packing list
Machine X1, casting knife x1, bar x1, vacuum pump x1, UV curing device x1, certificate of conformity X1, manual X1, warranty card X1
After-sales instructions
Warranty days: 365 days
非人为造成的产品质量问题，供应商无条件提供1年保修服务
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48639/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
