Specifications
| Display mode | digital display |
| Viscosity range | 20~2000000mPa·s |
| Rotor specification | L1#、L2#、L3#、L4# |
| reproducibility | ±0.5%F.S |
| Measurement Accuracy | ±1%F.S |
| Power supply Voltage | Dedicated power adapter (input 100~240V 50~60Hz) |
| temperature sensor | RTD |
| Rotor speed | 0.3/0.6/1.5/3/6/12/30/60rpm |
| Display information | Viscosity, Rotation speed, percentile torque, rotor number and the maximum measurable viscosity of the selected rotor at the current Rotation speed, etc |
| Thermostatic bath model | LC-1008 |
| Thermostatic bath Temperature range | -10～100℃ |
| Thermostatic bath Temperature control mode | Smart PID |
| Thermostatic bath Temperature Fluctuation | ±0.05～0.1℃ |
| Thermostatic bath Temperature Resolution | 0.1℃ |
| Thermostatic bath Volume | 8L |
| Thermostatic bath opening size | 175x145x150mm |
| Thermostatic bath hole number | 1 |
| Thermostatic bath cycle | Inner and outer circulation |
| Flow rate of Thermostatic bath pump | 12L/min |
| Thermostatic bath pump maximum pressure | 0.2bar |
| Maximum suction of thermostatic tank pump | 0.1bar |
| Thermostat Power Supply Voltage | 200~230，VAC |
| Thermostat external Dimensions | 415X410X426mm |
| Thermostat temperature display | LED |
| Thermostatic bath Heating power | 2000W |
| Thermostatic bath cooling Capacity (10 ° C) | 300W |
| Thermostatic bath pump type | Pressure/suction pump |
| Thermostatic bath pump connection | M16x1 |
| Thermostatic bath instrument fixing method | desktop |
| Thermostatic bath allows continuous operation | 100 |
| Thermostatic bath Environmental temperature | 5~32℃ |
| Thermostatic bath Relative Humidity | 80% |
| Thermostatic bath Frequency | 50Hz |
| Thermostatic bath meets standards | JJF 1030-2010 |
Packing list
Host X1, RTD temperature sensor X1, protection frame X1, rotor X1 (sleeve), base and horizontal adjustment bolt X1, lifting frame and lifting mechanism X1, special power adapter X1, wrench X1
