Specifications
| Measuring method | Platinum plate method (or platinum ring method) |
| Measurement range | 0-400mN/m |
| Minimum resolution | 0.01 mN/m |
| standard error | +/- 0.02mN/m 2 distillations at 20 ° C) |
| repeatability | +/- 0.02mN/m 2 distillations at 20 ° C) |
| Display mode | LCD display (add the display backlight panel, you can adjust the lighting time of the display panel, and the temperature display can be viewed directly on the Display) |
| read time | Usually 3 to 5 seconds. |
| platform lift | Slow lifting (add fast lifting function) |
| Signal output interface | RS232 (with 232 to USB cable and software) |
| Linear dispersion software | Standard |
| temperature sensor | PT:100 |
| test temperature | 0~100°C |
| Power supply Voltage | AC220V、50/60Hz |
| Dimensions (mm) | 400*200*400 |
| Net Weight (kg) | 15 |
| Ordinary thermostatic pool | optional |
| High and low temperature thermostatic pool | optional |
| Display temperature | optional |
Packing list
Host x1, hook x1, sample tray x1, Glass tray x2, alcoholburner x1, forceps x1, test weight x1, power cord x1, fuse x2, M3 hexagon wrench x1, U disk x1, computer connection x1, USB right lock x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48843/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
