Specifications
| Adapter output | Output Voltage: 5 V, maximum output current: 2 A |
| Operating temperature and Humidity | -10 ℃~50 ℃， ≤95% |
| Storage Temperature and Humidity | -20 ℃~60 ℃， ≤95% |
| Temperature Measurement Range | -20 ℃～550 ℃ |
| Temperature measurement Accuracy | +/- 2 ° C or +/- 2% of the reading (MAX Maximum) |
| Protection level | IP54 |
| anti-drop grade | 2m |
| Weight | 380 g (with battery) |
| size | 221.7 mm × 73.5 mm × 123.8 mm |
| Hardware Interface | Type-C |
| Electromagnetic Compatibility (EMC) | GB/T17799.2，GB 17799.3-2012 |
| Response band | 7.5~14μm |
| NETD (Noise Equivalent Temperature Difference) | < 50 mk(@25 °C, F#=1.0) |
| Thermal imagery field of view | 27.8°×37.2° |
| Temperature measurement unit | Celsius, Fahrenheit, Kelvin |
| Distance coefficient ratio | 60 |
| Infrared Detector resolution | 192×144 |
| Infrared image resolution | 640×480 |
| Thermal imagery lens focal length | 3.6mm |
| ISR super resolution | 384×288 |
| visible light | support |
| Image resolution | 1600×1200 |
| Battery type | Rechargeable Li-ion battery, 3350 mA * h, Rated Voltage: 3.6 V |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48848/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
