Specifications
| Lighting method | D/8° |
| Meet the standard | CIE No.15,GB/T 3978 |
| Sensor | silicon photodiode |
| Measurement caliber | Φ8mm |
| Color space | CIE LAB,LCh,XYZ |
| Observer Angle | CIE 10 ° Standard observer |
| Observational Light source | D65 |
| show | Chromatic value, color difference value/graph, pass/fail result, Color bias |
| Measurement time | 1.5s |
| Repeatability | Delta E * ab0.08 (average of 30 times) |
| stand-alone difference | Delta E * ab0.4 (BCRA series 12 color plate average) |
| size | 205X70X100mm |
| Weight | About 400g (including battery) |
| Battery | Rechargeable lithium-ion battery 3.7V@3200mAh |
| Light source | Lifespan 5 years greater than 1.60 million measurements |
| Display | TFT True Color 2.8inch @(16:9) |
| interface | USB |
| Store data | 100 master standards, 20,000 samples |
| Temperature range | 0~40'C(32~104°F) |
| Temperature range | -20~50°C(-4~122°F) |
| PC software | High-end host computer software |
| standard accessories | power adapter, manual, quality management software (download from the official website), data cable, wristband |
| Optional Accessories | Micro printer, powder test box |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48876/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
