Specifications
| Coating Method | continuous scratch coating |
| Effective application width | ≤ 300mm, adjustable through baffle |
| Drawdown blade adjustment | manual adjustment |
| Drawdown blade diameter | Ф80mm |
| Drawdown blade heating temperature | RT+~150°C |
| Spreader thickness range | 0.01mm~2mm |
| Minimum gluing thickness | 0.01Mm (depending on the slurry, refer to the material requirements) |
| Coating surface density | ≤ +/- 1.5% (including substrate, excluding edge abnormal areas, see product evaluation for sampling measurement standards) |
| Coating Speed | 2~ 4.5M/min forward and reverse stepless speed change, recommended Spreader speed: 4.5m/min |
| Film Accuracy | +/- 0.003mm (depending on slurry, reference material requirements) |
| Regulator Graduation | 0.001mm |
| Indication Display mode | digital display |
| Heating device | Chute heating |
| Heating mode | Heating rod |
| Temperature range | RT+~200℃ |
| box Volume | About 0.5L |
| Width of guide roller | 350mm |
| substrate width | Max.300mm |
| Back roller diameter | Ф150mm |
| Reel diameter | 3 inches. |
| winding diameter | Max.Ф200mm |
| Applicable materials | hot-melt adhesive |
| Machine Power | 1050W |
| Host Power Supply | AC220V (single phase) 50Hz |
| Machine size | 1280*600*660mm |
| Machine Weight | About 120kg |
| gas source | 0.5-0 MPa compressed air |
| unwinding diameter | Max.Ф200mm |
Packing list
host X1, glue melting furnace x1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
