Specifications
| Coating method | Drawdown blade |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Coating table size | 640*430mm |
| Effective coating Area | 400 * 400Mm (can be customized) |
| Drawdown blade thickness range | 0~10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 400mm |
| Drawdown blade Accuracy | ±0.003mm |
| Power | 400w |
| Display | Color LCD touch screen |
| Operating language | Chinese (can be customized in English) |
| Host Power Supply | 100V~220V/50~60HZ |
| Dimension | Subject to the actual product |
| optional feature | Heating, vacuum adsorption |
Packing list
Machine x1, casting knife x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/4891/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
