Specifications
| Coating method | Bar + drawdown blade |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Spreader Platform size | 940*330mm |
| Effective coating Area | 700 * 300Mm (can be customized) |
| Mayer Rod Thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Bar Accuracy | ±0.001mm |
| Drawdown blade thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 300mm |
| Drawdown blade Accuracy | ±0.003mm |
| Power | 400w |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Dimension | Subject to the actual product |
| optional feature | Heating, vacuum adsorption |
Packing list
Host X1, manual X1, fixture X1, Drawdown blade x1, imported bar X1, certificate X1
After-sales instructions
Warranty days: 730 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/48984/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
