Specifications
| coating method | Blade Coating |
| coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 1240*330mm |
| effective coating area | 1000 * 300Mm (can be customized) |
| Blade Coating Film thickness range | 0~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Blade Coating Width | 300mm |
| Blade Coating accuracy | ±0.003mm |
| Heating temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| Heating method | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| customization function | Electrostatic Precipitation System |
| operating language | Chinese (can be customized in English) |
| display screen | Color LCD Touchscreen |
| Host power supply | 100V~220V/50~60HZ |
| power | 1800w |
| dimensions | 1260*440*430mm |
Packing list
Host X1, manual X1, fixture X1, 300mm drawdown blade x1, 200mmx1, certificate X1
After-sales instructions
Warranty days: 730 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49003/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
