Specifications
| Furnace mode | open type |
| Furnace tube material | Quartz tube |
| Outer diameter of furnace tube | 50mm |
| Furnace tube length | 600mm |
| Thermostatic zone length | 100mm |
| Operating temperature | ≤1050℃ |
| Heating rate | Recommended within 10 ° C/min |
| Temperature control Accuracy | ±1℃ |
| Thermocouple | K type |
| heating element | Heating alloy wire |
| Sealing method | 304 stainless steel vacuum flange |
| flange interface | One end is a KF16 vacuum outlet, and the other end is a 1/4-inch gas inlet |
| Vacuum | 1Pa (mechanical pump) |
| Machine size | L940*D430*H430mm |
| Power supply | AC:220V 50Hz |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49004/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
