Specifications
| Coating method | Rod |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum adsorption + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 740*530mm |
| Mayer Rod Thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Mayer Rod Accuracy | ±0.001mm |
| Vacuum Area | 580 * 460Mm (can be customized) |
| vacuum aperture | Φ0.8mm |
| Vacuum hole spacing | 20*20mm |
| Pumping Speed | 5.4m3/h |
| Ultimate Vacuum | 50KPa |
| Vacuum Pump Power | 180W |
| Vacuum pump Weight | 7.1kg |
| Heating mode | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Effective coating Area | 500 * 500Mm (can be customized) |
| Heating Temperature range | RT +~ 180 ℃ (higher temperature can be customized) |
| Temperature Uniformity | ±1℃ |
| Coating speed | Stepless speed regulation through cylinder valve |
| customization function | Automatic feeding system |
| Feeding principle | Pneumatic pressure feeding |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2-150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Feeding system air source | Customer-provided compressed air, 0.6Mpa |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Power | 1800W |
Packing list
The whole machine x1, bar x1, automatic feeding system x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49005/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
