Specifications
| Coating method | Bar + drawdown blade |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Coating table size | 540*430mm |
| Effective coating Area | 300X400mm (can be customized) |
| Mayer Rod Thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Mayer Rod Accuracy | ±0.001mm |
| Drawdown blade thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 300mm |
| Drawdown blade Accuracy | ±0.003mm |
| substrate thickness | ≤ 50mm (customized) |
| UV Irradiance Intensity | 403mw/cm2 |
| UV Lamp Beads | 40 pieces |
| UV Lamp Input Voltage | AC85A-260V |
| UV Lamp Size | 300*130*130mm |
| UV lamp light effect | 500W |
| UV Lamp Power | 50W |
| Power | 400w |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 220V/50HZ (can be customized 110V/60HZ) |
| Dimension | 658*438*205mm（L*W*H） |
| optional feature | Heating, vacuum adsorption |
Packing list
Host X1, manual X1, fixture X1, drawdown blade x1, import bar X1, certificate X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49009/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
