Specifications
| Coating Method | Bar + drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum chuck + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Effective coating Area | 700 * 800Mm (can be customized) |
| Spreader platform size | 940*830mm |
| Meyer rod coating thickness Range | Different bar numbers Film thickness is different, with high Accuracy imported bar |
| Meyer rod coating Accuracy | ±0.003mm |
| Drawdown blade Spreader Film thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade Spreader width | 800mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Vacuum chuck size | 780 * 760Mm (can be customized) |
| Vacuum Aperture | Φ0.8mm |
| Vacuum hole pitch | 20*20mm |
| Drive motor | Servo motor |
| Vacuumpump pumping rate | 5.4m3/h |
| Ultimate Vacuum | 50KPa |
| power | 600w |
| Vacuumpump power | 180W |
| Vacuumpump Weight | 7.1kg |
| operating language | Chinese (can be customized in English) |
| standard feature | Automatic inking system |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2~150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Shaft transmission mode | Timer belt |
| Feeding system air source | 0.6Mpa, which can be connected to the trachea of < unk > 8 (self-equipped). |
| Feeding system power Voltage | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum Volume | 1L |
| Display | Color LCD touch screen |
| Host Power Supply | 220V/50HZ (can be customized 110V/60HZ) |
| Dimensions | 960*940*940mm |
Packing list
Film Applicator x1, bar x1, drawdown blade x1, automatic feeding system x1, vacuum pump x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
