Specifications
| Light source | Semiconductor Laser Light source (lifetime greater than 30,000 hours) |
| Sampling flow rate | Built-in vacuum pump, 2.83L sampling |
| particle size channel | Six channels, 0.3, 0.5, 1.0, 3.0, 5.0, 10 (μm) |
| Particle size distribution error | 0.5um 5um ≤±30% |
| An indication of particle concentration error | 0.5um ≤±30% |
| detection range | 100 to 1 million |
| UCL Report | In line with Chinese GMP standards |
| Sampling period | 1S - 9999999s self-set |
| Sampling Delay | 1S - 9999999s self-set |
| Sampling points | 2 - 50 points can be set arbitrarily |
| Sampling times | 2-50 times, any setting |
| Sampling area | According to requirements, any combination of letters and numbers or individually set |
| Sampling unit | Piece, Piece/m ³, Piece/FT3 and other three unit options |
| self-purification time | ≤10min |
| Operating Environment | Temperature 10 ℃ - 35 ℃ Relative Humidity ≤ 75% atmospheric pressure 86kPa - 106kPa |
| Sampling conditions | Sampling gas shall not contain acid, alkali, high temperature and other corrosion gases |
| data printing | Built-in high-speed thermal printer |
| Display mode | 5-Inch color touch screen |
| Battery Capacity | Built-in 4000mAh |
| average power consumption | 7.5W |
| Dimension | 220*230*130（W*L*H）mm |
| Weight | 2.8KG |
Packing list
host X1, power adapter X1, printing paper X1, manual X1, certificate X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49065/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
