Specifications
| operating Voltage | 50Hz,AC220V |
| Vacuum Pump Power | 200W |
| pumping rate | 108L/min |
| Ultimate Vacuum | -95KPa |
| Vacuum setting range | 0~-90KPa |
| Outer diameter of sealing barrel | Φ300×300mm |
| Effective size of standard vacuum chamber | Φ270X190mm |
| Standard vacuum chamber Volume | 15L |
| Measurement time | ≤ 999999S (time can be set freely) |
| Time control Accuracy | 1s |
| inflation rate | 2KPa.L/S |
| Operating Environment | -20~50 ℃ (-20 ℃~ 0 ℃ need to start practice running 3min) |
| total quantity of the whole machine | About 25KG |
| Main box size | 400X300X200mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49072/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
