Specifications
| Coating method | Drawdown blade |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum adsorption + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 450*180mm |
| Effective coating Area | 210 * 150Mm (can be customized) |
| Drawdown blade thickness range | 0~10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 150mm |
| Drawdown blade Accuracy | ±0.003mm |
| vacuum aperture | Φ0.8mm |
| Vacuum hole spacing | 20*20mm |
| Pumping Speed | 5.4m3/h |
| Vacuum Pump Power | 180W |
| Vacuum pump Weight | 7.1kg |
| Ultimate Vacuum | 50KPa |
| Power | 400w |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Dimension | 658*438*400mm |
Packing list
Host X1, manual X1, Drawdown blade x1, imported bar X1, certificate X1, vacuum pump X1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49136/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
