Specifications
| Spreader process | Roll → Scratch → Drying → Roll |
| Effective application width | Max.Φ600mm |
| Coating method | Slot-die extrusion |
| Cutting head type | Slot-die Spreader |
| Display mode indication | digital display |
| WFT | 0.005-3mm |
| Regulator Graduation | 0.001mm |
| Spreader Accuracy | ±5% |
| Coating speed | 1-10M/min (adjustable) |
| unwinding method | Inflatable shaft unwinding |
| winding method | Inflatable shaft winding |
| Outer diameter of winding air expansion shaft | 3-Inch expansion shaft, load-bearing 50KG |
| maximum discharge | Max.Φ600mm |
| maximum charge | Max.Φ600mm |
| Drying Temperature range | RT+~200℃ |
| Temperature control Accuracy | ±3℃ |
| Heating mode | hot air circulation |
| Oven length | 1M/section |
| Total length of drying tunnel | 10m |
| Drying Power | 1KW/section |
| Tension control range | Automatic constant tension (1-10N) |
| Tension control Accuracy | ±0.5N |
| Motor type | Servo motor |
| Control mode | PLC + touch screen |
| Human Machine Interface | Color touch screen |
| tension control | automatic |
| Correction control | automatic |
| thickness control | manual |
| Fitting method | Roll fit |
| Fitting speed | 0.1~ 10M/min (adjustable) |
| Fit width | Max.Φ600mm |
| gas source | 0.5~ 0.8MPa compressed air |
| Applicable coil type | Plastic film, metal foil, paper, non-woven fabric, etc |
| Spreader type | Water-based paints, solar-based paints, UV coatings, etc |
| Environmental temperature | 10℃ ~ 40℃ |
| Environmental humidity | 30～90%RH |
| power requirements | 380V, 50Hz, three-phase five-wire system |
| Total power consumption | 45KW (subject to actual customization) |
| Dimension | About 14000mm*1200mm*1600mm (subject to actual customization) |
| safety protection | emergency stop button |
Packing list
Host x1, Manual x1, Encasement List x1, Certificate of Conformity x1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
