Specifications
| Coating Method | Bar + drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Coating table size | 1440*630mm |
| Effective coating Area | 1200 * 600Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers Film thickness is different, with high Accuracy imported bar |
| Bar Accuracy | ±0.001mm |
| Drawdown blade Spreader Film thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade Spreader width | 600mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Dimensions | 1460 * 740 * 940Mm (subject to the actual product) |
| standard feature | Automatic feeding system |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2~150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Shaft transmission mode | Timer belt |
| Feeding system air source | 0.6Mpa, which can be connected to the trachea of < unk > 8 (self-equipped). |
| Feeding system power Voltage | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum Volume | 1L |
| power | 400w |
| Display | Color LCD touch screen |
| operating language | Chinese (can be customized in English) |
| Host Power Supply | 100V~220V/50~60HZ |
| optional feature | Heating, Vacuum chuck |
Packing list
Host X1, manual X1, fixture X1, Drawdown blade x1, imported bar X1, certificate X1
After-sales instructions
Warranty days: 730 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49148/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
