Specifications
| Spreader process | Unroll → Transfer Spreader → Fit → Unroll |
| Effective application width | Max.Φ300mm |
| Coating method | Transfer Spreader |
| Cutting head type | anilox roller |
| thickness | Customized according to customer requirements |
| Cutter head heating temperature | RT+~150℃ |
| Spreader Accuracy | ±3% |
| Coating speed | 1-10M/min (adjustable) |
| unwinding method | Inflatable shaft unwinding |
| winding method | Inflatable shaft winding |
| Outer diameter of winding air expansion shaft | 3-Inch expansion shaft, load-bearing 50KG |
| maximum discharge | Max.Φ300mm |
| Maximum charge | Max.Φ300mm |
| Tension control range | Automatic constant tension (1-10N) |
| Tension control Accuracy | ±0.5N |
| Motor type | Servo motor |
| Control mode | PLC + touch screen |
| Human Machine Interface | Color touch screen |
| tension control | automatic |
| Correction control | automatic |
| thickness control | manual |
| Fitting method | Roll fit |
| Fitting speed | 0.1~ 10M/min (adjustable) |
| Fit width | Max.Φ300mm |
| gas source | 0.5~ 0.8MPa compressed air |
| Applicable coil type | Plastic film, metal foil, paper, non-woven fabric, etc |
| Spreader type | Hot-melt adhesive, pressed gelatin, etc |
| Environmental temperature | 10℃ ~ 40℃ |
| Environmental humidity | 30～90%RH |
| power requirements | 380V, 50Hz, three-phase five-wire system |
| Total power consumption | 45KW (subject to actual customization) |
| Dimension | About 14000mm*1200mm*1600mm (subject to actual customization) |
| safety protection | emergency stop button |
Packing list
host x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
