Specifications
| Detect gas | Hydrogen chloride HCL |
| Range | 0~500ppm |
| resolution | 1PPM |
| Response time | T90≤20s |
| Linearity | ≤±1% |
| detection Accuracy | ≤±3% |
| Zero drift | ≤ +/- 1% (F. S/year) |
| recovery time | ≤20s |
| Repeatability | ≤±1% |
| expansion gas | Supports 1-4 Sensors |
| Explosion-proof sign | CNEx16.0538 |
| Protection level | IP65 |
| production license | Guangdong 00001052 (CMC metrology authentication) |
| Humidity | Optional accessories, temperature detection range: -40~120 ℃, Humidity detection range: 0~100% RH |
| Sampling method | pump suction |
| detection mode | Real-time detection, Timer detection can be set |
| Data storage | Real-time storage and timed storage can be set; 120,000 groups of data can be stored |
| Operating temperature | -30~60℃ |
| Environmental humidity | 0~95% RH non-condensing |
| Operating Pressure | -30~100Kpa |
| Power Supply | 4000mA rechargeable polymer battery |
| Dimension | 212*85*70mm |
| Net Weight | 0.45Kg |
| execution standard | GB3836.1-2010、GB3836.4-2010 |
| optional range | 0~10、20、100、200ppm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
