Specifications
| Flat field eyepiece | WF10X/< unk > 18mm can be matched with WF16X/< unk > 11mm |
| Eliminating color difference objective | 4X/0.10, 10X/0.25, 40X/0.65 (spring), 100X/1.25 (oil, spring) |
| Total Magnification | 40X-1600X |
| observation head | Hinged 45 ° tilt, 360 ° swirl/spin |
| converter | Four holes (inward ball positioning) |
| Coarse fine-tuning focusing range | 20Mm fretting grid value: 2um coarse fretting coaxial focusing, coarse elastic adjustable, with locking and limit |
| stage | Double-decked Mobile Platform size 110X110mm Moving range 60X20mm Cursor grid value 0.1mm |
| Mechanical barrel length | 160mm |
| pupil distance | 55-75mm |
| condenser | 1.25NA Abbe condenser, variable light bar with color filter (up and down lift) |
| lighting | 1WLED optional 220V halogen lamp, halogen tungsten bulb 6V12W |
| Net Weight | 2.4 kg |
| Gross Weight | 3.8 kg |
| instrument size | 22X36X36.5（cm） |
| Packaging Dimensions | 33.5X28X59(cm) |
| Imagery system | 5 million |
