Specifications
| Studio Volume | 408L |
| Interior size | 800*850*600mm |
| Dimension | 1250mm×1770mm×1155mm（W×H×D） |
| Temperature range | -60~150℃ |
| Temperature Resolution | 0.01℃ |
| Temperature deviation | ±0.5℃ |
| Temperature Uniformity | ≦ 2℃ |
| Temperature Fluctuation | ±0.5℃ |
| Heating rate | -60 ℃ → + 150 ℃ Average 3 ℃/min throughout the process |
| Humidification system | Stainless steel humidifier |
| Heating system | Nickel chromium alloy stainless steel heater |
| water supply system | Front-mounted water supply tank, fully automatic water supply system |
| communication interface | 1. R232/485 communication |
| setting method | Chinese/English interface, touch input |
| operation mode | Program method/valuation method |
| setting range | Temperature range 5 ℃ |
| Display resolution | Temperature: 0.01 ℃; Time: 0.1 min; |
| Power-off memory function | The power failure recovery mode can be set as: hot start/cold start/stop |
| input | platinum resistance |
| storage function | Standard configuration, recording test data Linear dispersion, can upload and download data, can expand storage Capacity |
| Software Operating Environment | IBM PC compatible machine, CPU above PII, memory above 128M, Simplified Chinese Windows2000 or Simplified Chinese WindowsXP operating system |
| Chassis shell | Cold rolled steel plate |
| Chamber material | SUS304 #stainless steel plate |
| Insulation material | 100Mm polyurethane rigid foam + 100mm high density fiberglass cotton |
| Standard configuration | φ 50 Test Hole, Lighting, Double-decked Glass Viewing Window |
| Weight | About 370kg |
| current | 22A |
| Rated power | 8.7kw |
| Power Supply | Three-phase, 380V |
| Humidity resolution | 0.1%R.H |
| Deviation deviation | ±2%R.H |
| Humidity Uniformity | ±3%R.H |
| Humidity stability | ± 2%R.H |
| Cooling rate | 150 ℃ → -60 ℃ Average 1 ℃/min throughout the process |
Packing list
Host X1, instruction manual X1, warranty card X1, equipment certificate X1, packing list X1, specimen rack tray X2, specimen rack support track hook X8
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49208/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
