Specifications
| maximum test force | 100KN |
| maximum test force | 100KN |
| Measurement range | 1% - 100% FS (full scale) |
| Measurement range | 1% - 100% FS (full scale) |
| Force Precision | ±1% |
| Force Precision | ±1% |
| Displacement measurement resolution | 0.01mm |
| Displacement measurement resolution | 0.01mm |
| Beam traverse speed | 0.1-500mm/min |
| Beam traverse speed | 0.1-500mm/min |
| effective stretch stroke | 680Mm (can be customized according to user request) |
| effective stretch stroke | 680Mm (can be customized according to user request) |
| effective compression stroke | 1100Mm (can be customized according to user request) |
| effective compression stroke | 1100Mm (can be customized according to user request) |
| effective test width | 400mm |
| effective test width | 400mm |
| Operating Environment | Room temperature is about 35 ° C, Relative Humidity does not exceed 80% |
| Operating interface | Operating interface is LCD display, menu is Chinese/English |
| Operating Environment | Room temperature is about 35 ° C, Relative Humidity does not exceed 80% |
| Dimension | 700X550x2000mm (customizable size) |
| Operating interface | Operating interface is LCD display, menu is Chinese/English |
| Dimension | 700X550x2400mm (plus work cabinet) |
| Dimension | 700X550x2000mm (customizable size) |
| Weight | About 380Kg |
| Power Supply | 220 +/- 10% VAC, Frequency 50Hz, 1.5kW |
| Dimension | 700X550x2400mm (plus work cabinet) |
| Weight | About 380Kg |
| Power Supply | 220 +/- 10% VAC, Frequency 50Hz, 1.5kW |
Packing list
Host X1, Power Cord X1, Manual X1, Fixture X1, Force Value Sensors X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49224/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
