Specifications
| maximum test force | 5000N |
| Force Precision | Level 1 |
| Measurement range | 2%--100%FS |
| Force value indication Accuracy | Better than indication +/- 1% |
| Force resolution | 1/3000 |
| Measurement Accuracy of beam displacement | Resolution higher than 0.01mm |
| Test speed range | 0.1 - 500mm/min, stepless speed regulation |
| Safety protection device | Mechanical limit protection and software overload protection |
| Effective compression stroke (with fixture stroke) | 1000Mm (can be customized according to user request) |
| Operating Environment | Room temperature - 35 ℃, Relative Humidity does not exceed 80% |
| leak size | 470×470×1510mm |
| Weight | About 110kg |
| Power supply for the whole machine | Single phase, 220V +/- 10%, 50Hz; 400W |
Packing list
Host X1, Power Cord X1, Manual X1, Fixture X1, Force Value Sensors X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49232/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
