Specifications
| foil | Copper foil, aluminum foil and PET film, etc. (material thickness 6-30um) |
| slurry | Water-based paints, battery slurries, electrolysis fluids, etc. (viscosity range < 3000cps) |
| Mechanical speed | Max 5m/min (production speed depends on slurry and coating requirements) |
| Coating thickness | Dry Weight 5um |
| wide range of materials | 210mm |
| pull width | 100-210mm |
| Substrate Weight | Max.50Kg |
| Tension control range | 1-50N |
| guide roller | Hard anodic oxidation treatment on roller surface |
| Spreader Dry-Film Error | Better than +/- average surface density of 20%, no large area leakage of foil phenomenon (related to slurry state) |
| Device size | About 1500mm long × 1200mm wide × 1700mm high |
| unwinding method | Roll up or down, maximum roll diameter 250mm |
| tension control | Tension can be set, PLC program control, forming a closed-loop tension control; |
| unwind drive | Servo motor 500W, precision planetary gear reducer 1 set, servo Controller 1 set |
| Deviation correction device | Motor correction push, stroke +/- 150mm, Accuracy +/- 0.5mm, ultrasonic testing (UT) edge sensor |
| roll over | φ 50mm × 300mm, aluminum roller surface anode treatment, mirror polishing treatment |
| operation button | Touch screen button switch control and emergency stop, start, stop, deviation correction manual/automatic buttons |
| Control mode | Equipment reference speed |
| Oven length | A total of 2 ovens; oven length 1000mm/section, a total of 1000mm |
| Oven Temperature range | Inside the box 40 ℃~ 200 ℃ (Environmental temperature 20 ℃) |
| Oven temperature Accuracy | Temperature control Accuracy +/- 2 ℃ |
| Electric heating | 8Kw/section, total 8kw |
| heater | Electric heating tube + stainless steel heat exchange fins |
| Box material | The inner and outer sides are stainless steel, and the insulation layer is rock wool board/silicic acid board. |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
