Specifications
| Coating table size | Adjustable (according to slot-die die specifications) |
| substrate size | Max 220x240mm Flatness: +/- 3μm; Maximum substrate heating temperature: 150 ℃ |
| Mechanical speed | Traverse speed 0-200mm/s (parameter can be set) |
| substrate thickness | 0.02-10 mm for flexible and rigid glass substrates |
| Substrate clamping method | Vacuum adsorption |
| Spreader platform material | Marble base + high-precision stainless steel adsorption platform |
| Feeding system | High-precision liquid supply pump + corrosion resistant pipeline + luer joint |
| Feeding speed | 0-10Ml/min14; supply Accuracy: 0.05ml/s0.05-5mm/s; advance supply time: 0-10s |
| Spreader uniformity | Film thickness uniformity ≤ 3% -5% (depending on Spreader process, inks, substrate) |
| applicable viscosity | 1-3000Cps (various oily/water-based UV adhesives, inks and other solvents) |
| Air knife | Equipped with aluminum alloy nitrogen air knife |
| Installation size | L740mm*W444mm*H425mm |
| Control mode | AC servo + gear reducer + screw + grating feedback + PLC automatic/touch screen control |
| Coating method | extrusion coating |
| Lip height | 0~5Mm, adjustable |
| Adjustment Accuracy | A. Digital dial: 1um |
| Coating Accuracy | +/- 2μm (reference value depends on slurry characteristics) |
| Die head model | TG-C200 |
| Die head material | SUS630 |
| Die Accuracy | Lip straightness ≤ 3μm |
| cavity Volume | 8ml |
| gasket width | Opening width Max. 200mm |
| Gasket thickness | 30/50/70/100/200um (choose thickness according to solution viscosity) |
| Weight | About 120Kg |
| Power Supply | 380V/50HZ, Power 5KW |
Packing list
host X1, manual X1, certificate X1, warranty card X1, wrench X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49276/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
