Specifications
| Spreader type | Continuous Spreader |
| Applicable system | hot-melt adhesive |
| Width of guide roller | 330mm |
| substrate width | Max.300mm |
| application width | 0-280Mm, adjustable through baffle |
| Mechanical speed | 5m/min |
| Spreader thickness | Continuous Spreader minimum thickness on one side: 0.01mm (depending on the slurry, reference material requirements), thickness Accuracy ： ≤ +/- 5μm (excluding edge abnormal areas, see product evaluation for sampling measurement standards) |
| Drawdown blade diameter | Ф60mm |
| align both sides | +/- 0.5mm (length direction) |
| box Volume | About 0.5L |
| Back roller diameter | ≤ 80mm, roller runout ≤ 5μm |
| Heating mode | Heating rod |
| heating temperature | 0-200 degree adjustable |
| rewinding diameter | Max.Ф200mm |
| Rewinding and unwinding core | Ф76mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49278/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
