Specifications
| Frequency modulation range (Hz) | 5~600 |
| Sweep range (Hz) | 5~600 |
| Maximum Acceleration (m/s2) | 170 |
| Maximum test load (kg) | 40 |
| Maximum no-load displacement (mmp-p) | 0~ 2 (automatic adjustment) and 0~ 5 (manual adjustment) |
| vibration waveform | sine wave |
| vibration axis | Vertical + Horizontal |
| Excitation mode | Electromagnetic excitation |
| Control mode of vibration | closed loop control |
| Data acquisition method | Vibration data collection + Acceleration Sensors |
| Acceleration Sensors | 2 Piezoelectric Acceleration Sensors (Built-in Shaker Table) |
| operating mode | Frequency mode (constant amplitude mode and constant acceleration mode), frequency sweep mode (constant amplitude scan and constant acceleration scan), multi-segment mode (constant amplitude mode and constant acceleration mode) |
| Platform shock absorber | 1 set (suitable for high floors and laboratories) |
| Sweep mode | linear |
| Operation mode | Computer control |
| Cooling mode | air-cooled |
| Operating temperature requirement (℃) | 0~+40 |
| Operating humidity requirement (% RH) | 0-90, no condensation |
| power requirements | Three-phase AC 380V/50Hz +/- 10% |
| System Power Consumption (KVA) | 7.5 |
| Display parameters | 19 inch, capacitive touch screen all-in-one machine |
| Work surface material | aluminum alloy |
| Countertop screw size (standard) | M8 (can be customized) |
| Number of Countertop screws | 8 (can be customized) |
| Total Weight of the platform (kg) | 370 |
| Work surface size W.D.H (mm) | 750×750×43 |
| Table size W.D.H (mm) | 750×750×650 |
| Control cabinet size W.D.H (mm) | 600×580×1600 |
Packing list
Host X1, manual X1, certificate X1, warranty card X1, simple fixture X1, power cord X1, control cable X1, U disk X1, computer (computer host + monitor + keyboard and mouse set) X1
