Specifications
| Frequency modulation range (Hz) | 1~600 |
| Sweep range (Hz) | 1~600 |
| Maximum Acceleration (m/s2) | 170 |
| Maximum test load (kg) | 60 |
| No-load random maximum amplitude (mmp-p) | 0~ 5 (adjustable range) |
| vibration waveform | sine wave |
| vibration axis | 3-Axis all-in-one machine (up and down, left and right and front and rear) |
| Excitation mode | Electromagnetic excitation |
| Control mode of vibration | open loop control |
| Data acquisition method | Vibration data collection + Acceleration Sensors |
| Acceleration Sensors | 1 (External Shaker Table) |
| Sensor type | Piezoelectric Acceleration Sensors |
| operating mode | Fixed Frequency Mode (Constant Frequency, Arbitrarily Set Time); Sweep Mode (Upper Frequency/Lower Frequency/Timer Range) Can be arbitrarily set, Sweep Frequency back and forth; Multi-segment mode (Programmable function, Frequency range can be arbitrarily set Frequency/time, can be cycled); Random mode |
| function | FM, Sweep, Programmable, AM, Maximum Acceleration, Time Control |
| Platform shock absorber | 1 set (suitable for high floors and laboratories) |
| Isolation magnetic field function | Alloy panels can completely isolate magnetic fields |
| Sweep mode | Linear, logarithmic |
| Operation mode | Touch screen control + computer software control (excluding computer host) |
| Cooling mode | air-cooled |
| Operating temperature requirement (℃) | 0~+40 |
| Operating humidity requirement (% RH) | 0-90, no condensation |
| power requirements | Single phase AC 220V/50Hz |
| System Power Consumption (KVA) | 2.8 |
| Work surface material | aluminum alloy |
| Countertop screw size (standard) | M8 (can be customized) |
| Number of Countertop screws | 8 (can be customized) |
| Total Weight of the platform (kg) | 200 |
| Work surface size W.D.H (mm) | 550×550×43 |
| Table size W.D.H (mm) | 1100×800×680 |
| Control cabinet size W.D.H (mm) | 420×300×750 |
Packing list
host X1, operation manual X1, warranty card X1, certificate X1, simple fixture X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
