Specifications
| Integrating sphere size | Φ40mm |
| Light source | Light spectrum LED Light source |
| spectroscopy | Plane grating spectroscopy |
| Sensor | Silicon photodiode array (dual row 40 groups) |
| Measurement Wavelength range | 360-780nm |
| wavelength interval | 10nm |
| Bandwidth | 5nm |
| Transmittance Measurement Range | 0~200% |
| Observer Angle | 2°/10° |
| Measurement time | Fast mode about 0.8s |
| Repeatability | Spectroscopic transmittance: standard deviation within 0.05% (400~700nm: within 0.04%): chromatic value: Delta E * ab within 0.015 (after preheating correction, measurement at intervals of 5S) |
| stand-alone difference | Delta E * ab within 0.25 |
| size | Length X width X height = 370X300X200mm |
| Weight | About 9.6kg |
| Power Supply | DC 24V, 3A power adapter Power Supply |
| Light source lifetime | More than 3 million measurements in 5 years |
| Display | TFT true color 7inch, capacitive touch screen |
| interface | USB, print serial port |
| Store data | 1000 master standards, 10000 samples, Massive storage of the host computer |
| Special features | Smart zero calibrating |
| language | Simplified Chinese, Traditional Chinese, English |
| Temperature range | 0~40℃（32~104°F） |
| Temperature range | -20~50℃（-4~122°F） |
| Note: | Subject to change without notice |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49318/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
