Specifications
| volume | 12L |
| Rated power | 9kw |
| heating rate | ≤10℃/min |
| Heating the workpiece | silicon molybdenum rod |
| Common temperature | 1550℃ |
| maximum temperature | 1700℃ |
| Temperature control instrument | 30-Segment intelligent program control |
| Temperature measuring element | Type B Thermocouple |
| Thermostatic accuracy | ±1℃ |
| Furnace material | High purity aluminum oxide polycrystalline fiber Curing Oven |
| Furnace door structure | side opening |
| Furnace size | 300*200*200 |
| Dimension | 570*470*765mm |
| Power supply voltage | 380V |
| Product features | Can quickly raise and cool, furnace temperature field balance. Temperature control is stable, easy to operate, low energy consumption |
| function | Over-current protection, break-even prompt, over-temperature alarm function |
| main accessories | Asbestos gloves, crucibletong, Thermocouple |
| Optional accessories | Furnace, control software (can remotely monitor, modify heater status program Linear dispersion) |
Packing list
After-sales instructions
Warranty days: 365 days
