Specifications
| Light spectrum range | UVC：230nm-280nm λp = 254nmUVB：280nm-315nm λp = 310nmUVA：315nm-400nm λp = 365nmUVV：395nm-445nm λp = 420nm |
| Power Measurement Range | 0 ~ 2000 mW/cm2 |
| Power resolution | 0.01 mW/cm2 |
| Power data storage interval | 32 times/second |
| Energy Measurement Range | 0 ~ 999999mJ/cm2 |
| Energy measurement Accuracy (H is the standard value) | H < 5mW/cm2: +/- 0.5mW/cm2H > = 5mW/cm2: +/- 10% H, +/- 5% H Typical |
| Temperature Measurement Range | -55°C ~ +125°C |
| Temperature data storage interval | 2 times/second |
| Sampling speed | 2048 times/second |
| recording period | 32 minutes |
| show | 240 * 160 point matrix LCD |
| instrument size | Diameter 120mm * Film thickness 13mm |
| instrument Weight | About 248g |
| operating power consumption | 117mW |
| Operating Current | 39mA |
| Instrument Power Supply | 2 AAA alkaline dry batteries |
| supply Voltage | DC 3V |
Packing list
UV irradiometer x1, AAA alkaline battery x4, manual x1, warranty card x1, engineering box size 34 * 29 * 9 cm (length * width * height) x1
After-sales instructions
Warranty days: 365 days
If the product quality is caused by non-human factors, the manufacturer will provide 1 year free warranty service (except accessories and consumables);
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49364/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
