Specifications
| Lighting method | Reflection: D/8 (diffuse illumination, 8 ° direction reception); SCI/SCE measurement; including UV/exclude UV measurement; transmission: D/0 (diffuse illumination, 0 ° direction reception) SCI/SCE measurement; including UV/exclude UV measurement; haze (ASTM D1003); meets CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7, JIS Z8722 Condition C |
| Integrating sphere size | Φ154mm |
| Measurement caliber | Reflection: XLAV φ 25.4mm/φ 30mm LAV φ 15mm/φ 18mm MAV φ 8mm/φ 10mm SAV φ 4mm/φ 6mm Transmission: φ 25.4mm (Sample height and Film thickness are not limited, Film thickness ≤ 54mm) Remarks: 1. Switch the diameter and automatically identify 2. Customers can configure the diameter and lens position according to their needs |
| Reflectance resolution | 0.01 |
| Reflectance Measurement Range | 0~200% |
| lighting source | 360~780Nm combined LED light source, including UV, 400nm cut-off light source, 420nm cut-off light source, 460nm cut-off light source |
| spectroscopy | Concave grating |
| Light-containing method | Reflection SCI/SCE, Transmission SCI/SCE |
| observation light source | D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, DLF, TL83, TL84, TPL5, U30, B, U35, NBF, ID50, ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LED-V1, LED-V2, LED-C2, LED-C3, LED-C5, customizable light sources (41 light sources in total, partially realized through the host computer) |
| Measurement Wavelength range | 360~780nm |
| wavelength interval | 10nm |
| Half bandwidth | 5nm |
| Measurement time | About 2.0s (about 4s for simultaneous SCI/SCE testing) |
| Observer Angle | 2°/10° |
| stand-alone difference | φ 25.4mm/SCI, Delta E * ab within 0.15 (BCRA series ⅱ 12 color plate measurement average) |
| Operating temperature range | 0~40℃（32~104°F） |
| Lifetime of lighting source | More than 3 million measurements in 5 years |
| Sensor | 256 pixel dual array CMOS image sensor |
| Sexual repeability | Reflection chromatic value: φ 25.4mm/SCI, Delta E * ab within 0.015 (after instrument preheating correction, 30 average standard deviation of whiteboard measurement at intervals of 5s) Light spectrum reflection/transmittance: ≤ 0.1% |
| Power Supply | DC 24V, 3A power adapter Power Supply |
| Storage temperature range | -20~50℃（-4~122°F） |
| Store data | 64G storage space, more than 100,000 pieces (SCI/SCE counts as one piece of data) |
| show | Light spectrum plots/data, sample chromatic values, color difference values/plots, chromaticity plots, Color simulation, pass/fail results, Color bias, Color evaluation, Haze, Liquid chroma |
Packing list
machine x1, manual x1, certificate x1
