Specifications
| structure | All-in-one machine (Fe/NFe) |
| Probe | Ruby probe for 90 degree swirl/spin, measurement of inner tubes and small space coatings |
| Probe area | φ8mm |
| Minimum test radius of curvature | Convex: 6mm, Concave: 38mm |
| Measurement range | Fe：0-5000um，NFe：0-2000um |
| Display resolution | 1- 100um: 0.1um，> 100um: 1 um，>1000um:10um |
| Accuracy | Less than 100um: +/- 1um, 100 - 1000um: +/- 1%, 1000 - 2000um: +/- 3%, ≥ 2000um: +/- 5% |
| Power supply | 1.5V AA battery |
| Display | Highlight OLED display |
| language | German, English |
| calibrate | With zero point, single point correction function |
| shutdown | Automatic/manual shutdown |
| unit conversion | With metric-to-inch conversion function um /mils: |
| statistical data | (Measured, MAX Maximum, MIN Minimum, Average, Standard deviation) |
| Stored readings and statistical displays | 4000 value storage, freely grouped |
| LED graphic display lighting | have |
| Bluetooth interface | Low energy Bluetooth interface for Android, iOS and Windows |
| APP application acquisition | Google Play Store, Apple App Store, List-Magnetik official website for free |
| purpose | It is used for the measurement of all insulation coatings thickness on non-ferrous metals (aluminum, zinc, copper, etc.), such as anodic oxide coatings, paints, coatings, etc. It is also used for the measurement of the thickness of all nonmagnetic coating platings on steel, such as paints, plastics, enamels, chromium, zinc, etc. |
| Meet the standard | ISO 2178, ISO 2360 |
| Protection Rating | IP64 |
| Dimension | Φ28 x 95 mm |
Packing list
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49421/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
