Specifications
| Coating method | Bar + drawdown blade |
| Coating speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum adsorption + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 940*630mm |
| Effective coating Area | 700 * 600Mm (can be customized) |
| Mayer Rod Thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Mayer Rod Accuracy | ±0.001mm |
| Drawdown blade thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 700mm |
| Drawdown blade Accuracy | ±0.003mm |
| Vacuum Area | 780 * 560Mm (can be customized) |
| vacuum aperture | Φ0.8mm |
| Vacuum hole spacing | 20*20mm |
| Pumping Speed | 5.4m3/h |
| Ultimate Vacuum | 50KPa |
| Vacuum Pump Power | 180W |
| Vacuum pump Weight | 7.1kg |
| Heating mode | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Heating Temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| motor | Servo motor |
| Operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| Power | 1800w |
| Dimension | 960*740*430mm |
| Weight | 40kg |
Packing list
Host X1, manual X1, drawdown blade x1, import bar X1, certificate X1, vacuum pump X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49435/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
