Specifications
| detection range | 0-5mm |
| detection channel | 1 (can be expanded to 8) |
| number of independent detection frequencies | single frequency |
| frequency range | 10Hz-16MHz, step 1KHz |
| Crazing detection Accuracy | Length × width × depth 3mm × 0.1mm × 0.1mm (using a flat probe to detect steel test blocks) |
| Pipe detection Accuracy | 0.3Mm through hole up to 8db (20mm inner penetration probe) copper pipe |
| Gain Range | 0.0-99, step: 0.1/0/1 dB |
| Phase swirling/spinning | 0-359 ° continuously adjustable, step 1/5/10 Deg |
| signal-to-noise ratio | ≥10dB |
| Gain ratio | （Y/X）：0.1-10.0 |
| probe drive | January 8 |
| Linear dispersion | equivalent amplitude |
| digital filtering | Low-pass: 0Hz-2000Hz; Qualcomm: 0Hz-2000Hz |
| number of filter points | 0-1024 |
| broadband | 10Hz-16MHz |
| A/D rate | 12bit 80M |
| Automatic equilibrating | Digital electronic equilibrate |
| display mode | Impedance, Time Base, Circular Hole, Cartesian Coordinates, Polar Coordinates |
| scanning speed | Level 1-1000 |
| Automatic equilibrating | Digital electronic equilibrate |
| Hardware real-time sampling | 10-Bit AD converter, sampling speed 160MHz |
| Alarm mode | Real-time alarm |
| Alarm window | Fan, Cube |
| Window adjustment | Levels 1 to 12 |
| storage type | 64G hard disk |
| test data | More than 10,000 groups |
| detection parameter | More than 10,000 groups |
| display characteristics | 6- and 8-inch color TFT-LCD LCD display with resolution resolution 1024X760 |
| standby time | 8h |
| interface | LEMO-6 DB-15 |
| Magnetic memory sensitivity | 5Gs |
| Appearance size | 230 mm × 180 mm ×90 mm |
| Machine Weight | 1.8kg |
Packing list
After-sales instructions
Warranty days: 365 days
