Specifications
| detection range | 1.5-300 mm (Note: The user should select the corresponding Sensors model according to the diameter of the wire rope to be inspected, and the detection range of different Sensors is different) |
| detection efficiency | 0.0-6 m/s (relative speed of sensor and wire rope) |
| Optimum detection efficiency | 0.3 -1.5 m/s |
| allowed clearance | 0-15Mm (allowable clearance between guide sleeve and wire rope) |
| optimal clearance | 2 -6 mm |
| Qualitative Accuracy of broken wire | 99.99% |
| Broken wire error | One or one equivalent root misjudgment is allowed |
| Single centralized broken wire number error-free quantitative detection | More than 100 times Accuracy rate ≥ 92% |
| Sensitivity error | ±0.055% |
| Accuracy error of indication | ±0.2% |
| An indication of length error | ±0.2% |
| Power Supply | Computer battery powered by 5V |
| Sensors Weight | Common specification < 10kg |
Packing list
After-sales instructions
Warranty days: 365 days
