Specifications
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Drawdown blade Spreader Film thickness range | 0.01~10mm |
| Coating Speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Effective coating Area | 400*300mm |
| Meyer rod coating thickness Range | 1~ 571.5 μm (Spreader Film thickness according to bar type) |
| Meyer rod coating Accuracy | ±0.001mm |
| Drawdown blade material | 304 stainless steel |
| Host Power Supply | 220V 50Hz 1700W |
| Dimensions | 626*410*520mm |
| Weight | Subject to the actual product |
| speed control | Infinitely variable speed |
| Bottom plate material | Glass |
| Spreader Itinerary | Digital arbitrary setting within the range of 1~ 400mm |
| UV curing area | 400*300mm |
| UV light main peak wave | 36nm |
| UV light power | 400*2W |
| UV light curing wavelength | 350~450nm |
| switch | Aviation plug/separate switch |
| Light source spacing | 18*18mm |
| Lamp board height from coating table | 20Mm (support customized adjustable height) |
| Shaft transmission mode | Timer belt |
| Ink-jet principle | Air pump |
| Sport mode | Reciprocating linear motion (single ink) |
| Back and forth traverse speed | 2-150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the operating speed of the discharge port) |
| Feeding system air source | 0.6Mpa, can be connected to the trachea of φ 8 (self-equipped) |
| Feeding system power Voltage | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum Volume | 1L |
| Coating Method | Bar + drawdown blade |
Packing list
Film Applicator x1, bar x1, Drawdown blade x1, UV curing device x1, automatic feeding system x1, manual x1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/4960/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
