Specifications
| Rated Voltage | AC100~240V |
| Rated Frequency | 50/60 Hz |
| Input Power | 162 W |
| output power | 110 W |
| drive type | Brushless DC Motor |
| Output torque of stirring shaft | 13.1 N.cm |
| Output peak torque of stirring shaft | 39 N.cm |
| Duty Cycle | S1 (continuous) |
| Control mode | Capacitive Touch Keyboard |
| Rotation speed adjustment range | 30~2000 rpm |
| Rotation speed control type | Promise |
| Timer Range | 1-6000 min |
| Distance status display | TFT |
| Overload protection function | Yes |
| Rotation speed dynamic detection function | Yes |
| Rotation speed trend Linear dispersion function | Yes |
| Rotation speed memory function | Yes |
| Stirringrod fixing method | Quick Collet (Material: 3Cr13 Stainless Steel) |
| Rotary collet clamping range | 2-10 mm |
| Stirringrod penetration diameter (shutdown) | 8 mm |
| Impeller configuration | 4-Blade Spiral Impeller (Material: SS 316L Stainless Steel) |
| Processing Capacity (H2O) | 20L |
| stirring viscosity treatment | 0-20000 mPa.s |
| Environmental temperature | Not more than 40 ° C |
| Allowable Relative Humidity | Not more than 80% |
| Protection level | IP40 |
| Dimensions of the whole machine | 215x310x600 mm |
| vertical Volume of the whole machine | 7.6 kg |
Packing list
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49604/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
