Specifications
| Thermal conductivity range | 0.0020～2.0000 W/(m·K) |
| resolution | 0.0001 W/(m·K) |
| Thermal resistance range | 0.02～4 (m2·K)/W |
| Hot Plate Temperature range | RT+10～100℃ |
| Temperature range of cold plate | RT～80℃ |
| Hot Plate temperature control Accuracy | ±0.02℃ |
| Temperature Resolution | 0.01℃ |
| Measurement Accuracy | ±3% |
| Repeatability | ±1% |
| Thickness resolution | 0.01mm |
| Thickness range | 1~ 50Mm automatic measurement |
| Pressurization method | Automatic pressurization |
| Pressure resolution | 0.1Kpa |
| Pressure range | 0~4Kpa automatically adjustable |
| Sample size | 300mm×300 mm×(5-50 mm) |
| Interface | Standard USB port |
| reference standard | GB/T 10294ASTM C177ISO 8302 |
Packing list
machine x1, manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
