Specifications
| Meet the standard | IEC 651.2, ANSI 1.4.2 |
| Measurement parameter | Lp - Normal sound level measurement Leq - Equivalent sound level measurement Lmax - Maximum sound level measurement LN - Statistical sound level measurement |
| Measurement range Lp - normal sound level | A Weighting: 30~130dB C Weighting: 35~ 130dB Linear: 40~130dB |
| Measurement range Leq - equivalent sound level | 30~130dB (time can be selected from 10 seconds, 1 minute, 5 minutes, 10 minutes, 15 minutes, 30 minutes, 1 hour, 8 hours, 24 hours) |
| Measurement range LN - Statistical sound level measurement | 0~100% |
| resolution | 0.1dB |
| Precision | 1dB |
| Frequency Weighting | “A”/“C”/“F”(Flat) |
| time Weighted | Fast/slow |
| Microphone | 12.5Mm condenser microphone |
| memory function | 30 groups |
| Built-in calibration signal | 94dB |
| Frequency range | 20~12,500Hz |
| Alarm settings | 30~130dB |
| Alarm output | LED optional relay contact point |
| Power supply Voltage indication | Low Voltage prompt |
| External power socket | 6V, DC, 100mA |
| size | 236x63x26mm |
| Weight | 170g |
| Optional Accessories | ND9 Acoustic calibrator USB Connectivity Cable and Software, Bluetooth Adapter and Software |
Packing list
Host X1, windshield X1, portable case (B04) X1, instruction manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49658/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
