Specifications
| maximum test force | 1000N |
| Force value Accuracy | Level 1 |
| Force Measurement Range | 2%--100%FS |
| Force value indication Accuracy | Better than indication +/- 1% |
| Force resolution | 1/3000 |
| Beam displacement measurement Accuracy | Resolution higher than 0.01mm |
| Test speed range | 0.1 - 500mm/min, stepless speed regulation |
| Safety protection device | Mechanical limit protection and software overload protection |
| test space | 650Mm (can be customized according to user request) |
| Operating Environment | Room temperature - 35 ℃, Relative Humidity does not exceed 80% |
| leak size | 470×470×1210mm |
| Weight | Approx. 90 kg |
| Power supply for the whole machine | Single phase, 220V +/- 10%, 50Hz; 400W |
Packing list
Host X1, Power Cord X1, Manual X1, Fixture X1, Force Value Sensors X1
After-sales instructions
Warranty days: 365 days
1.仪器设备非人为造成的产品质量问题，在质保期内厂家提供免费质保服务；
2.易损易耗配件不存在质保期，收到货发现产品质量问题，请在7天内申请退换货，逾期不候；
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49672/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
