Specifications
| Coating Method | Bar + drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | Vacuum chuck + fixture |
| Coating table material | Surface hard treatment aluminum alloy |
| Coating table size | 1240*530mm |
| Effective coating Area | 1000 * 500Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers Film thickness is different, with high Accuracy imported bar |
| Meyer rod coating Accuracy | ±0.001mm |
| Drawdown blade Spreader Film thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade Spreader width | 500mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Vacuum chuck size | 1080 * 460Mm (can be customized) |
| Vacuum Aperture | Φ0.8mm |
| Vacuum hole pitch | 20*20mm |
| Vacuumpump pumping rate | 5.4m3/h |
| Ultimate Vacuum | 50KPa |
| Vacuumpump power | 180W |
| Vacuumpump Weight | 7.1kg |
| Heating method | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Heating temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| Drive motor | Servo motor |
| operating language | Chinese (can be customized in English) |
| Display | Color LCD touch screen |
| Host Power Supply | 100V~220V/50~60HZ |
| power | 1800w |
| Dimensions | 1260*640*940mm |
| Weight | 40kg |
Packing list
Host X1, manual X1, drawdown blade x1, import bar X1, certificate X1, Vacuumpump X1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49691/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
