Specifications
| Temperature range | Room temperature -1550 ℃ |
| Temperature Resolution | 0.01℃ |
| Temperature Fluctuation | ±0.1℃ |
| Heating rate | 0.1~100℃/min |
| Temperature control method | PID algorithm control, heating, thermostatic |
| Balance Measurement range | 0.01mg～3g |
| Control mode | Program control to achieve multi-stage temperature control; the program can be set to at least 5 stages |
| Weighing system Accuracy | 0.01mg |
| Display mode | 24Bit color, 7-inch LCD touch screen display |
| atmosphere control | Dual independent airflow control device, automatic switching of software programming |
| The furnace is chilled down | Air-cooled: 1000 ℃ -50 ℃ ≤ 13min (with water-cooled separately) |
| software | Intelligent software can automatically record TG Linear dispersion for data processing and print experimental reports |
| Power Supply | AC220V 50Hz |
| Heating power | ≤1000w |
| operating software | Data collection Frequency can be customized settings, set acquisition Frequency real-time, 2S, 5S, 10S Yes, custom |
| System architecture | Top Loading, Vertical Balancing System, No Radiation Screen Design, Optimized Airflow Condition, Less Pollution, Easy Operation |
| Communication interface | USB communication, two-way communication |
| Miscellaneous | Instrument lower machine with temperature multi-point correction, at least 3 points correction, high, medium and low temperature, no need to operate on the computer to complete, instrument with initial atmosphere, purge and emptying function, program control, before the experiment runs, the emptying time is set |
Packing list
thermogravimetric host X1, U disk X1, data cable X2, power cord X1, ceramic crucible X200, ceramic cover X2, metal cover X1, raw tape X1, standard tin X1, 10A fuse X5, sample spoon/sample pressure rod/forceps X1, dust cleaning ball X1, trachea X2, manual X1, warranty X1, certificate X1
After-sales instructions
Warranty days: 730 days
1. For product quality problems caused by instruments and equipment not artificially, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49701/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
