Specifications
| Weighing readability | 0.001g |
| Weighing range | 220g |
| Water readability | 0.01% |
| Sensors | Imported German HBM |
| heating source | Halogen lamp (ring 450w) |
| Heating method | Gentle, standard, fast |
| shutdown mode | Automatic shutdown, manual shutdown, timed shutdown |
| The result shows | Test Temperature, Test Time, Moisture Content, Solid content, Drying Weight, Dynamic Linear dispersion diagram, Moisture regain, Solid content, Weight loss, Dry Weight, Test method, Sample name, MAX Maximum, MIN Minimum, Average |
| data storage | 100 groups |
| user management | Password protection, multiple users, automatic locking |
| shutdown standard | Freely definable |
| Sample disc diameter | φ 90mm [stainless steel material] |
| Heating temperature range | 40-200 ° C (1 ° C interval) (up to 230 ° C can be customized) |
| display | 5-Inch touchscreen display |
| Communication interface | Standard RS232 communication interface, can connect printers, PCs and Miscellaneous peripherals, can be customized USB |
| Product size | Length, width and height 220 × 340 × 210mm net Weight 3.8kg |
| Outer box size | Length, width and height 430 × 290 × 330mm Gross Weight 4.8kg |
Packing list
Host X1, stainless steel sample plate X2, tripod bracket X1, heat collector plate X1, corrected weight X1, certificate X1, manual X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by instruments and equipment not artificially, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49707/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
