Specifications
| Coating Method | Bar + Drawdown blade |
| Coating Speed | 1~ 300Mm/s stepless speed regulation (can be customized) |
| Substrate clamping method | fixture |
| Coating table material | Glass plate |
| Coating table size | 1740*730mm |
| Effective coating Area | 1500 * 700Mm (can be customized) |
| Meyer rod coating thickness Range | Different bar numbers have different thicknesses, with high-precision imported bars |
| Bar Accuracy | ±0.001mm |
| Drawdown blade Coating thickness range | 0.1~ 10Mm (clamshell design is easy to clean) |
| Drawdown blade material | Die steel |
| Drawdown blade application width | 700mm |
| Drawdown blade Spreader Accuracy | ±0.003mm |
| Dimension | 1760 * 840 * 940Mm (subject to the actual product) |
| standard feature | Automatic feeding system |
| Feeding principle | Air source pressure flows out |
| Feed Sport Mode | Reciprocating linear motion |
| Feeding back and forth traverse speed | 2~150mm/s |
| spit Volume | Adjustable (by adjusting the air pressure and the running speed of the discharge port) |
| Shaft transmission mode | Timer belt |
| Feeding system air source | 0.6Mpa, which can be connected to the trachea of < unk > 8 (self-equipped). |
| Power Voltage of charging system | 220V,50Hz |
| Tank pressure | Maximum withstand 8Mpa |
| Material of feeding barrel | 304 stainless steel with a wall thickness of 4mm |
| Feeding bucket configuration | Safety valve, pressure regulating valve, pressure gauge, discharge valve |
| Feeding drum Volume | 1L |
| Heating mode | Mica sheet heating (optional graphene heating, faster thermal conductivity) |
| Temperature range | RT +~ 180 ℃ (can be customized) |
| Temperature Uniformity | ±1℃ |
| Power | 400w |
| Display | Color LCD touch screen |
| Operating language | Chinese (can be customized in English) |
| Host Power Supply | 100V~220V/50~60HZ |
| optional feature | Heating, Vacuum chuck |
Packing list
Drawdown blade x1, bar x1, automatic feeding system x1, manual x1, certificate x1
After-sales instructions
Warranty days: 730 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49710/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
