Specifications
| display mode | digital display |
| Measurement Range | 20~2000000mPa·s |
| Rotor specification | L1#、L2#、L3#、L4# |
| reproducibility | ±0.5%F.S |
| measurement Accuracy | ±1%F.S |
| Power Supply | Dedicated power adapter (input 100~240V 50~60Hz) |
| Rotor speed | 0.3/0.6/1.5/3/6/12/30/60rpm |
| Display information | Viscosity, rotational speed, percentile torque, rotor number and the maximum viscosity value that can be measured at the current rotational speed of the selected rotor, etc |
| Temperature display | LED |
| Temperature control mode | Smart PID |
| Controlled temperature transducer | PT 100 |
| operation temperature range | Room temperature + 5~ 100 ℃ |
| Display Accuracy | 0.1℃ |
| Temperature Fluctuation | +0.05～0.1K |
| heating power | 2000W |
| Pump type | Pressure/suction pump |
| Pump maximum pressure | 0.2bar |
| pump maximum suction | 0.1bar |
| Pump connection | M16x1 |
| Sink Volume | 8L |
| Instrument fixing method | desktop |
| Allow continuous operation | 1 |
| Allowable environment temperature | 5~32℃ |
| Allowable Relative Humidity | 1 |
Packing list
After-sales instructions
Warranty days: 3650 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/49742/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
